V0 Flame Retardant Polyester Pet Braided Sleeving

V0 Flame Retardant Polyester Pet Braided Sleeving

V0 Flame Retardant Polyester Pet Braided Sleeving

Product group: V0 Flame Retardant Polyester Pet Braided Sleeving

Product features:

MATERIAL : POLYESTER ( PET ) V0
MONOFILE DIA. : 0,22 MM , 0,25 MM
STANDARD : DIN 5510
CERTIFICATE : CE, ROHS
OPERATING TEMPERATURE: -50°C / +120°C ( SHORT TERM +150C )
COLOR : GREY ( RAL 7031 ) , BLACK ( RAL 9011 )
FLAMMABILITY CLASS : UL94 V0

FEATURES

BEST GRADE MATERIAL
HALOGEN FREE
SULPHUR FREE
PHOSPHORUS FREE
ABRASION RESISTANT
BENZINE
SOLVENT AND ACID RESISTANT
UL 94V0 FLAME RETARDANCY
SELF-EXTINGUISH
HIGH MECHANICAL STRENGTH
EASY INSTALLATION
UV RESISTANT (BLACK COLOUR)

APPLICATIONS

MACHINE INDUSTRY
AUTOMATION SYSTEMS
AUTOMOTIVE
SOLAR SYSTEMS
CONSTRUCTION
ROBOT APPLICATIONS
SHIP INDUSTRY

Product description:

BLACK CODE	GREY CODE	HOSE DIA.	MIN. EXPANSION DIA. (MM)	MAX. EXPANSION DIA. (MM)	REEL LENGTH (M)
AGRV0-5-S	AGRV0-5-G	5	3,0	10,0	100
AGRV0-8-S	AGRV0-8-G	8	4,0	13,0	100
AGRV0-10-S	AGRV0-10-G	10	5,0	16,0	100
AGRV0-12-S	AGRV0-12-G	12	7,0	19,0	100
AGRV0-15-S	AGRV0-15-G	15	10,0	25,0	100
AGRV0-20-S	AGRV0-20-G	20	13,0	30,0	100
AGRV0-25-S	AGRV0-25-G	25	16,0	38,0	50
AGRV0-30-S	AGRV0-30-G	30	19,0	40,0	50
AGRV0-40-S	AGRV0-40-G	40	31,0	55,0	50
AGRV0-50-S	AGRV0-50-G	50	40,0	68,0	50
