Polyamide Ventilation Plug

Polyamide Ventilation Plug

Polyamide Ventilation Plug

Product group: Polyamide Ventilation Plug

Product features:

MATERIAL : POLYAMIDE 6
STANDARD : EN 62444
THREAD TYPE : METRIC EN 60423
PROTECTION CLASS : IP 68 / 5 BAR
OPERATING TEMPERATURE : -30°C /+100°C,-40°C /+150°C (SHORT TERM)
FLAMMABILITY CLASS : UL94V2
COLOR : GREY (RAL 7001), BLACK (RAL 9005), LIGHT GREY (RAL 7035)
O-RING : NBR MEMBRANE : PTFE ( HYDROPHOBIC )
SEAL : TPV, (CHLOROPRENE IS OPTIONAL)
CLOSING SEAL : TPV
CERTIFICATE : CE, ROHS

FEATURES

PERFECT VENTILATION PERFORMANCE
HIGH MECHANICAL STRENGTH
EASY INSTALLATION
HIGH STRAIN RELIEF
BEST GRADE MATERIAL
ACID RESISTANT

APPLICATIONS

LIGHTING
CABINETS
MACHINE BUILDINGS
AUTOMATION SYSTEMS
MARINE , SHIPYARD

Product description:

STANDARD THREAD

GREY CODE	BLACK CODE	LIGHT GREY CODE	SIZE	AVERAGE AIR FLOW ( I / H )	WATER INTRUSION PRESSURA (BAR)	TD (MM)	TL (MM)	SW (MM)	H (MM)
TMOV-M12/1-G	TMOV-M12/1-S	TMOV-M12/1-AG	M12X1,5	16,0	0,8	12,0	6,0	18,0	11,0	50
TMOV-M12/2-G	TMOV-M12/2-S	TMOV-M12/2-AG	M12X1,5	25,0	0,5	12,0	6,0	18,0	11,0	50”
TMOV-M12/3-G	TMOV-M12/3-S	TMOV-M12/3-AG	M12X1,5	130,0	0,2	12,0	6,0	18,0	11,0	50
TMOV-M12/4-G	TMOV-M12/4-S	TMOV-M12/4-AG	M12X1,5	300,0	0,1	12,0	6,0	18,0	11,0	50”
