Plastic Braided Sleeving

Plastic Braided Sleeving

Plastic Braided Sleeving

Product group: Plastic Braided Sleeving

Product features:

MATERIAL : POLYESTER ( PET )
MONOFILE DIA. : 0,22 MM , 0,25 MM
STANDARD : DIN 5510
CERTIFICATE : CE, ROHS
OPERATING TEMPERATURE: -50°C / +120°C ( SHORT TERM +150C )
COLOR : GREY ( RAL 7031 ) , BLACK ( RAL 9011 )
FLAMMABILITY CLASS : UL94 HB

FEATURES

BEST GRADE MATERIAL
HALOGEN FREE
SULPHUR FREE
PHOSPHORUS FREE
ABRASION RESISTANT
BENZINE
SOLVENT AND ACID RESISTANT
UL 94 HB FLAME RETARDANCY
HIGH MECHANICAL STRENGTH
EASY INSTALLATION
UV RESISTANT (BLACK COLOUR)

APPLICATIONS

MACHINE INDUSTRY
AUTOMATION SYSTEMS
AUTOMOTIVE
SOLAR SYSTEMS
CONSTRUCTION
ROBOT APPLICATIONS
SHIP INDUSTRY

Product description:

BLACK CODE	GREY CODE	HOSE DIA.	MIN. EXPANSION DIA. (MM)	MAX. EXPANSION DIA. (MM)	REEL LENGTH (M)
AGR-5-S	AGR-5-G	5	3,0	10,0	100
AGR-8-S	AGR-8-G	8	4,0	13,0	100
AGR-10-S	AGR-10-G	10	5,0	16,0	100
AGR-12-S	AGR-12-G	12	7,0	19,0	100
AGR-15-S	AGR-15-G	15	10,0	25,0	100
AGR-20-S	AGR-20-G	20	13,0	30,0	100
AGR-25-S	AGR-25-G	25	16,0	38,0	50
AGR-30-S	AGR-30-G	30	19,0	40,0	50
AGR-40-S	AGR-40-G	40	31,0	55,0	50
AGR-50-S	AGR-50-G	50	40,0	68,0	50
