MATERIAL : POLYPROPLYENE HALOGEN FREE
STANDARD : EN 61386-2
PROTECTION CLASS : IP68
OPERATING TEMPERATURE : -25C / +95C
FLAMMABILITY CLASS : UL94 V2
COLOUR : GREY (RAL 7001),LIGHT GREY (RAL 7035),ALTERNATE COLOURS AVAIL.
COMPRESSION STRENGTH : 750 N
CERTIFICATE : CE, ROSH
INSULATION : HFFR
SHEATH : HFFR
OPERATING TEMPERATURE : - 30 C - 70 C
TEST VOLTAGE (AC) : 1,0 KV
MIN. BENDING RADIUS : 10XD
OPERATING VOLTAGE : 300 V
HALOGEN FREE TEST : IEC 60754 - 1/2
FLAME RETARDANCY TEST : IEC 60332 - 1/2
FLAME PROPAGATION TEST : IEC 60332 -3/24
ADDITIONAL FEATURE : LEAD FREE
